JAY PARTS PITMAN⁺ POLARIS SCRAMBLER 1000 S (55″) & SPORTSMAN 1000 S (55″)

JAY PARTS PITMAN⁺ Polaris Scrambler 1000 S & Sportsman 1000 S

The Jay Parts Pitman is made of high-strength steel and the highlight is the double clamping and the high material quality.

WHAT IS THE PROBLEM RESOLVED?
Steering play is 80% a worn Pitman. The models before 2013 was without clamping and from 2014 was provided with a clamp. The best way to check it is if someone moves the handlebars and you are watching with a flashlight just under the power steering the teeth. 1 mm play between Pitman and gearing is 8 - 10mm at the handlebar end!

FEATURES:
- S355 steel
- gusset plates
- reinforced
- double clamping
- FAG bearing custom made
- Made in Europe

Replaces article number: 1830308 + 5145220 +1824742 + 5142900

RECOMMENDATION
For installation, we also recommend checking the tie rod ends first and also changing them during play. JP0166 is the matching article number of the tie rod ends.
The installation by your specialist workshop is advisable and is recommended.

WORKS WITH THE FOLLOWING MODELS WITH EPS
Polaris Scrambler 1000 S (55"), 2020 - current
Polaris Sportsman 1000 S (55"), 2020 - current
