Demon Powersports PAXL-1129XHD Rear/Right, Center/Left

SALE 292,50  292,50

HEAVY DUTY X-TREME Axle

  • made of 4340 Chromoly steel
  • dual heat treated
  • maximum diameter of the axle and CV-joint
  • re-engineered cage design
  • wide articulation angles (up to 45 degrees)
  • high quality Moly grease
  • TPEE boot

Availability : 3 - 7 days

In stock

Description

DEMON HEAVY DUTY X-TREME AXLES

The new Heavy Duty X-treme axles are designed for use in extreme terrain, whether mud, rock or sand.

Demon Powersports strength test comparison

4340 Chromoly Steel & Dual Heat Treatment

The X-treme axles are made from durable, heat treated 4340 chromoly steel, one of the strongest materials in the industry for axles. With an excellent strength to weight ratio, Demon’s HDX trucks are born for the challenge!

Large articulation

The in board joint is designed to allow up to 40 degrees articulation and the outboard joint articulation varies from 45-47 degrees depending on the model.

Precision CNC Machined

Every single axis is CNC precisely engineered to achieve the best quality. Whether you’re traveling with mud tires, track sets or racing, Demon HDX trucks have been designed to handle the toughest conditions.

Re-engineered cage design

The articulated cage has been redesigned to improve strength and thus ease of handling.

Demon Powersports Acle cage comparison

TPEE boot

Thermoplastic polyester-elastomar boot offer ideal strength with dynamic flex to withstand the various temperature ranges.

Maximum runtime

The HDX axles are filled with cooling synthetic lithium molybdenum grease to maximize the runtime.

Ready for installation

The HEAVY DUTY X-TREME axles can be mounted on the ATV / UTV without modification.

These axles exceed the quality and expectations often found in OEM or other axles. The axle and each joint are maximized for ultimate power transmission.

It is recommended to always exchange the axles in pairs.

NOTE:
Polaris Sportsman 550 / Polaris Sportsman 850
Due to different tolerances the series knuckles a slight grinding of series cast nose may be required to optimize the free space of the outer joints.
If you have any questions, please contact our TECHNIK TEAM

Warranty HDX

DEMON POWERSPORTS WARRANTY HEAVY DUTY X-TREME DRIVE SHAFTS
LIMITED WARRANTY

Demon X-Treme Axles (excluding boots & clamps) are warrantied to the original purchaser for aperiod of 2 years from date of purchase.
DEMON POWERSPORTS warranty does not apply to failure resulting from misuse, negligence, accident, improper application, improper installation or alteration. Within 1 year from date of purchase, Demon Powersports will ship a replacement one time only at Demon Powersports’s discretion if the vehicle was not used in racing or military use (for example highlifter).
If the axle fails after 1 year but within two years from the date of purchase, the buyer will receive a replacement axle for a flat fee of USD 100. The warranty can be claimed one time only.

The warranty does not cover CV boots and clamps. Checking the boots and clamps should be part of the vehicle owner’s periodic vehicle check.

Jay Parts assumes for its customers a possible handling of the warranty claim.
For this you have to send an e-mail in advance with the following information:

your contact information
a description of the use of the damage
photos of the broken axle/ axle damage
photo center axle with imprint PAXL-xxxx
photo of the vehicle on which the installed suspension is recognizable
photo of the vehicle on which the tire dimension is recognizable
info vehicle / model / year in which the axle was installed
scan / photo bill/invoice

Jay Parts will contact you immediately and discuss the further procedure.

If there is a legitimate warranty claim, we will send you a form, which you must complete and return to us with the broken axle. This must be done within 15 days, otherwise the warranty expires. We will try to cover the warranty on our stock. If this is not possible, we will try to find the quickest and least expensive way for you to claim your warranty.

Please note, however, that in addition to the abovementioned warranty, the pro rata shipment to Europe + customs and import tax is added, which are not covered by Demon Powersports!
This currently amounts to approx. Euro 54, – incl. 20% VAT for 100% warranty and approx. € 174, – incl. 20% VAT for a warranty claim within the second year + shipping from Austria to customer address.

KAT/CAT Marke/Brand Jahr/Year Modell/Model
KAT/CAT Marke/Brand Jahr/Year Modell/Model
Demon Powersports CAN AM 2006 Outlander 400 STD|XT
Demon Powersports CAN AM 2006 - 2008 Outlander 650 STD|XT
Demon Powersports CAN AM 2006 Outlander MAX 400 STD|XT
Demon Powersports CAN AM 2007 Outlander 500 STD|XT
Demon Powersports CAN AM 2007 - 2008 Outlander 800 STD|XT
Demon Powersports CAN AM 2007 - 2009 Outlander 400 EFI STD|XT
Demon Powersports CAN AM 2007 - 2014 Outlander MAX 400 EFI STD|XT
Demon Powersports CAN AM 2007 Outlander MAX 500 STD|XT
Demon Powersports CAN AM 2007 - 2008 Outlander MAX 650 STD|XT
Demon Powersports CAN AM 2007 - 2008 Outlander MAX 800 800 STD|LTD|XT
Demon Powersports CAN AM 2007 Renegade 800 EFI
Demon Powersports CAN AM 2008 - 2009 Renegade 500
Demon Powersports CAN AM 2008 - 2012 Outlander 500 EFI|STD|XT
Demon Powersports CAN AM 2008 - 2012 Outlander MAX 500 EFI STD|DPS|XT|LTD
Demon Powersports CAN AM 2008 Renegade 800 800|800X
Demon Powersports CAN AM 2009 Outlander 650 EFI XT
Demon Powersports CAN AM 2009 Outlander 800 800R EFI XT
Demon Powersports CAN AM 2009 Outlander MAX 650 EFI XT
Demon Powersports CAN AM 2009 Outlander MAX 800 800R EFI LTD|XT
Demon Powersports CAN AM 2009 Renegade 800 800R EFI STD|X
Demon Powersports CAN AM 2010 - 2011 Outlander 650 EFI
Demon Powersports CAN AM 2010 - 2011 Outlander 800 800R EFI
Demon Powersports CAN AM 2010 - 2011 Outlander MAX 650 EFI
Demon Powersports CAN AM 2010 - 2011 Outlander MAX 800 800R EFI LTD
Demon Powersports CAN AM 2010 - 2011 Renegade 500 EFI
Demon Powersports CAN AM 2010 Renegade 800 800R EFI STD|XXC
Demon Powersports CAN AM 2011 - 2014 Outlander 400 EFI STD|XT
Demon Powersports CAN AM 2011 Outlander 800 800R EFI XMR|XXC
Demon Powersports CAN AM 2011 Renegade 800 800R EFI|EFI XXC
Demon Powersports CAN AM 2012 Outlander 1000 EFI STD|XT
Demon Powersports CAN AM 2012 Outlander 650 EFI STD|XT
Demon Powersports CAN AM 2012 Outlander 800 800R EFI STD|XT|XMR
Demon Powersports CAN AM 2012 Outlander MAX 650 EFI XT|XTP
Demon Powersports CAN AM 2012 Outlander MAX 800 800R EFI STD|XT|XTP
Demon Powersports CAN AM 2012 RENEGADE 1000 EFI STD|XXC
Demon Powersports CAN AM 2012 - 2014 Renegade 500 EFI STD
Demon Powersports CAN AM 2012 Renegade 800 800R EFI STD|XXC
Demon Powersports CAN AM 2013 - 2014 Outlander 1000 EFI DPS|XT|XT-P
Demon Powersports CAN AM 2013 Outlander 450 STD|DPS|PRO|Hunter Edition
Demon Powersports CAN AM 2013 - 2014 Outlander 500 EFI STD|DPS|XT
Demon Powersports CAN AM 2013 - 2014 Outlander 650 EFI STD|DPS|XT
Demon Powersports CAN AM 2013 - 2014 Outlander 800 800R EFI STD|DPS|XT|XT-P
Demon Powersports CAN AM 2013 - 2014 Outlander MAX 1000 EFI DPS|XT|XT-P|LTD
Demon Powersports CAN AM 2013 - 2014 Outlander MAX 500 EFI STD|DPS|XT
Demon Powersports CAN AM 2013 - 2014 Outlander MAX 800 800R EFI STD|DPS|XT|XT-P
Demon Powersports CAN AM 2013 - 2014 Renegade 1000 EFI STD|XXC
Demon Powersports CAN AM 2013 - 2014 Renegade 800 R EFI STD|XXC
Demon Powersports CAN AM 2013 - 2015 Outlander 650 EFI XMR
Demon Powersports CAN AM 2013 Outlander MAX 650 EFI STD|DPS|XT
Demon Powersports CAN AM 2014 Outlander 451 STD|DPS|PRO|Hunter Edition
Demon Powersports CAN AM 2014 Outlander MAX 650 EFI STD|DPS|X|XT-P
Demon Powersports CAN AM 2015 - 2017 Outlander 1000 EFI
Demon Powersports CAN AM 2015 Outlander 1000 EFI|XMR-DPS
Demon Powersports CAN AM 2015 Outlander 400 EFI STD (INTNATIONAL ONLY)
Demon Powersports CAN AM 2015 Outlander 452 STD|DPS|PRO|Hunter Edition
Demon Powersports CAN AM 2015 Outlander 500 EFI MAX
Demon Powersports CAN AM 2015 - 2017 Outlander 650 EFI
Demon Powersports CAN AM 2015 - 2018 Outlander 800 800R EFI
Demon Powersports CAN AM 2015 Outlander MAX 1000 EFI|EFI LTD
Demon Powersports CAN AM 2015 Outlander MAX 400 EFI STD|XT INTL
Demon Powersports CAN AM 2015 - 2018 Outlander MAX 500 EFI
Demon Powersports CAN AM 2015 Outlander MAX 650 EFI
Demon Powersports CAN AM 2015 - 2018 Outlander MAX 800 800R EFI
Demon Powersports CAN AM 2015 Renegade 1000 EFI
Demon Powersports CAN AM 2015 - 2018 Renegade 500 EFI
Demon Powersports CAN AM 2015 - 2018 Renegade 800 R EFI
Demon Powersports CAN AM 2016 Outlander 1000 DPS|XT|XT-P
Demon Powersports CAN AM 2016 Outlander 1000 XT
Demon Powersports CAN AM 2016 Outlander 453 STD|DPS|PRO|Hunter Edition
Demon Powersports CAN AM 2016 Outlander 500 STD|DPS|PRO
Demon Powersports CAN AM 2016 Outlander 570 EFI
Demon Powersports CAN AM 2016 Outlander 650 STD|DPS|XT
Demon Powersports CAN AM 2016 Outlander 650 XT
Demon Powersports CAN AM 2016 Outlander 850 DPS|XT|XT-P|XMR
Demon Powersports CAN AM 2016 Outlander L 570 EFI|L XMR
Demon Powersports CAN AM 2016 Outlander MAX 1000 XT|XT-P|LIMITED
Demon Powersports CAN AM 2016 Outlander MAX 400 ALL MODEL
Demon Powersports CAN AM 2016 - 2017 Outlander MAX 650 DPS|XT
Demon Powersports CAN AM 2016 Outlander MAX 850 XT|XT-P
Demon Powersports CAN AM 2016 RENEGADE 850 EFI STD|XXC
Demon Powersports CAN AM 2016 Renegade 1000 EFI STD|XXC|XMR
Demon Powersports CAN AM 2017 - 2018 Outlander 1000 DPS|XT|XMR|XTP|XXC|Hunter
Demon Powersports CAN AM 2017 Outlander 454 STD|DPS|PRO|Hunter Edition
Demon Powersports CAN AM 2017 Outlander 501 STD|DPS|PRO
Demon Powersports CAN AM 2017 - 2018 Outlander 650 DPS|XT|PRO|North Edition
Demon Powersports CAN AM 2017 - 2018 Outlander 850 EFI DPS|XT|XMR|XTP|XXC|NORTH EDITION
Demon Powersports CAN AM 2017 - 2018 Outlander 850 MAX EFI XT|XTP|NORTH EDITION
Demon Powersports CAN AM 2017 - 2018 Outlander MAX 1000 EFI
Demon Powersports CAN AM 2017 Renegade 1000 R
Demon Powersports CAN AM 2017 Renegade 850 EFI STD|XXC
Demon Powersports CAN AM 2018 OUTLANDER 455 STD|DPS|PRO|Hunter Edition
Demon Powersports CAN AM 2018 OUTLANDER MAX 650 DPS|XT
Demon Powersports CAN AM 2018 Outlander 1000 1000R EFI EXCEPT XMR
Demon Powersports CAN AM 2018 Outlander 1000 EFI T3
Demon Powersports CAN AM 2018 Outlander 450 EFI
Demon Powersports CAN AM 2018 Outlander 502 STD|DPS|PRO
Demon Powersports CAN AM 2018 - 2019 Outlander 570 EFI STD|DPS|PRO| XT|XMR|HUNTER
Demon Powersports CAN AM 2018 - 2019 Outlander 570 EFI T3 DPS|XT|PRO
Demon Powersports CAN AM 2018 - 2019 Outlander 570 MAX EFI T3|STD|DPS|XT
Demon Powersports CAN AM 2018 Outlander 650 EFI (NOT XMR)
Demon Powersports CAN AM 2018 Outlander 650 EFI T3
Demon Powersports CAN AM 2018 Outlander MAX 1000 EFI T3
Demon Powersports CAN AM 2018 Outlander MAX 450 EFI
Demon Powersports CAN AM 2018 Outlander MAX 570 EFI |EFI PRO (NOT XMR)
Demon Powersports CAN AM 2018 Outlander MAX 650 EFI (NOT XMR)
Demon Powersports CAN AM 2018 Outlander MAX 650 EFI T3
Demon Powersports CAN AM 2018 Outlander MAX 850 EFI EXCEPT XMR
Demon Powersports CAN AM 2018 RENEGADE 850 EFI STD|XXC
Demon Powersports CAN AM 2018 Renegade 1000 R EFI T3
Demon Powersports CAN AM 2018 Renegade 570 EFI
Demon Powersports CAN AM 2018 Renegade 650 EFI T3
Demon Powersports CAN AM 2019 Outlander 450 EFI T3 EXCEPT DPS
Demon Powersports CAN AM 2019 Outlander MAX 450 EFI T3
Demon Powersports CAN AM 2019 Outlander MAX 570 EFI DPS|XT T3
